Product Description
The HL-A161B Examination Couch is designed to provide a stable, adjustable, and comfortable platform for patient examination and clinical care. Its heavy-duty steel construction provides a strong foundation for regular healthcare use, while the PVC-cushioned top offers a comfortable surface for patients during examinations and procedures.
The couch features electrically controlled Hi-Low adjustment, operated by a convenient foot pedal. The height can be adjusted from 480mm to 920mm, allowing healthcare professionals to select a suitable working height for different examination and treatment requirements.
The back section can be adjusted from -33° to 90°, while the foot section adjusts from -24° to 41°. Both sections use gas-spring mechanisms for smooth and convenient positioning.
For mobility, the couch is equipped with four retractable medical-grade castors. When stability is required, four large pad leveling feet provide a secure base. An adjustable armrest is also available as an optional feature.
With a 230kg loading capacity, the HL-A161B offers a practical combination of patient comfort, positioning flexibility, mobility, and stability for modern clinical environments.
Key Features
- Heavy-duty steel construction for reliable clinical use
- PVC-cushioned patient surface for improved comfort
- Electrically controlled Hi-Low adjustment
- Foot-pedal operation for convenient height adjustment
- Height adjustment from 480–920mm
- Gas-spring adjustable back section
- Back section adjustment from -33° to 90°
- Gas-spring adjustable foot section
- Foot section adjustment from -24° to 41°
- Adjustable armrest available as an optional feature
- Four retractable medical-grade castors
- Four large pad leveling feet for stable positioning
- Maximum loading capacity of 230kg
- Suitable for examination and clinical care applications
Technical Specifications
| Specification | Details |
|---|---|
| Model | HL-A161B |
| Product Type | Examination Couch |
| Overall Size | L1980 × W700 × H480–920mm |
| Construction | Heavy-duty steel |
| Top Surface | PVC cushioned |
| Height Adjustment | 480–920mm |
| Height Adjustment System | Electric, foot pedal controlled |
| Back Section | -33° to 90° |
| Back Adjustment | Gas spring |
| Foot Section | -24° to 41° |
| Foot Adjustment | Gas spring |
| Armrest | Adjustable, optional |
| Castors | 4 retractable medical-grade castors |
| Leveling Feet | 4 large pad leveling feet |
| Loading Capacity | 230kg |
Positioning & Mobility
The HL-A161B provides flexible patient positioning through its electrically adjustable height and gas-spring-assisted back and foot sections. The wide adjustment ranges allow the couch to be configured for different examination and clinical requirements.
The four retractable medical-grade castors support convenient movement when needed, while the four large pad leveling feet provide stable support when the couch is positioned for examination or treatment.
Ideal For
The HL-A161B Examination Couch is suitable for:
- Medical examination rooms
- Clinics
- Hospitals
- Outpatient departments
- General clinical examination
- Patient assessment and positioning
- Routine treatment and healthcare procedures
