The Medical Dry Imager Printer is a high-performance thermo-graphic film printer designed to produce clear, accurate, and high-resolution diagnostic images for CT, MRI, DR, CR, and X-ray systems. Utilizing advanced direct dry thermal imaging technology, the printer delivers consistent image quality without requiring chemicals or water, making it an efficient and environmentally friendly solution for modern hospitals, diagnostic centres, and radiology departments. It supports seamless integration with DICOM and PACS systems, helping streamline medical imaging workflows.
Key Features
- Advanced Direct Dry Thermal Imaging Technology
- Compatible with CT, MRI, DR, CR, and Digital X-ray Systems
- Chemical-Free & Water-Free Printing
- High Resolution up to 508 DPI
- 12–14 Bit Grayscale for Superior Image Quality
- DICOM 3.0 & PACS Compatible
- Supports Multiple Medical Film Sizes
- Fast Printing Speed up to 90 Sheets per Hour
- Quiet, Compact, and Low-Maintenance Design
- Automatic Image Density Calibration
- Reliable Ethernet (RJ45) and USB Connectivity
- Designed for Hospitals, Clinics & Diagnostic Centres
Key Attributes
| Attribute | Details |
|---|---|
| Product Type | Medical Dry Imager Printer |
| Printing Technology | Direct Dry Thermal Imaging |
| Application | CT, MRI, DR, CR, Digital X-ray Imaging |
| Image Quality | High Resolution Diagnostic Printing |
| Connectivity | DICOM 3.0, Ethernet (RJ45), USB |
| Film Type | Medical Dry Thermal Film |
| Installation | Easy Integration with PACS Systems |
| Maintenance | Low Maintenance, Chemical-Free Operation |
| Usage | Hospitals, Imaging Centres, Radiology Departments |
Technical Specifications
| Specification | Details |
|---|---|
| Printing Technology | Direct Dry Thermal Imaging |
| Resolution | 320 DPI / 508 DPI |
| Grayscale Resolution | 12–14 Bit (Up to 4096 Shades) |
| Supported Film Sizes | 8″×10″, 10″×12″, 11″×14″, 14″×17″ |
| Print Speed | 70–90 Sheets per Hour |
| Network Protocol | DICOM 3.0 |
| Connectivity | Ethernet (RJ45), USB |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption | ≤600W (Printing), ≤75W (Standby) |
| Operating Temperature | 5°C – 35°C |
| Storage Temperature | -22°C – 50°C |
| Operating Humidity | 35% – 85% RH |
| Storage Humidity | 30% – 95% RH |
| Certifications | CE, ISO |
| Warranty | 1 Year* |
