Core Features and Advantages
-
Wireless Mobility with Wired Backup
This wireless flat panel detector supports high‑speed wireless communication via 802.11 ax/ac/n/a/g (2.4G & 5 GHz) for free movement during examinations. A wired backup connection ensures stable data transfer when needed, combining flexibility and reliability in one device.
-
High‑Sensitivity Imaging & Low‑Lag Performance
Equipped with a CsI scintillator and a‑Si TFT array, the detector delivers 574 LSB/μGy sensitivity, enabling high‑quality imaging at lower radiation doses. The <0.5% lag (after 60 seconds) ensures clear sequential images, essential for dynamic and continuous radiography workflows.
-
AED Integration & Smart System Functions
Built‑in AED (Automatic Exposure Detection) enables hands‑free imaging, improving workflow efficiency and reducing user intervention. The system supports both wireless and wired transfer, ensuring seamless integration with standard digital radiography setups.
-
High Durability for Clinical Environments
The wireless flat panel detector is engineered for heavy clinical use:
- Drop resistance: up to 70 cm
- Local load capacity: FTLV14C 120 kg; FTLV17C 300 kg
- Robust housing: compliant with ISO 4090 standards
These features ensure reliability in busy, demanding hospital environments.
- Long‑Lasting Battery & Wide Environmental Tolerance
- Battery autonomy: 4 hours (normal use), 8 hours (standby)
- Operating temperature: 10–35°C
- Operating/storage humidity: 10–90% RH
- Storage temperature: -10–50°C
The detector maintains stable performance across diverse clinical and transport conditions.
Technical Specifications Table
| Parameter | FTLV14C | FTLV17C |
|---|---|---|
| Brand | Fatali | Fatali |
| Model | FTLV14C | FTLV17C |
| Product Type | Wireless Flat Panel Detector | Wireless Flat Panel Detector |
| Detector Technology | a‑Si TFT + photodiode | a‑Si TFT + photodiode |
| Scintillator | CsI | CsI |
| Pixel Pitch | 140 μm | 140 μm |
| Active Area | 350 × 427.3 mm | 433.2 × 433.2 mm |
| Wireless Standard | 802.11 ax/ac/n/a/g (2.4G & 5 GHz) | 802.11 ax/ac/n/a/g (2.4G & 5 GHz) |
| Wired Transfer | Supported | Supported |
| AED | Yes | Yes |
| Sensitivity | 574 LSB/μGy | 574 LSB/μGy |
| Lag | <0.5% after 60 seconds | <0.5% after 60 seconds |
| DQE (1 lp/mm) | 0.48 | 0.48 |
| Maximum Linear Dose | 88 μGy | 88 μGy |
| Battery Life (Normal) | 4 hours | 4 hours |
| Battery Life (Standby) | 8 hours | 8 hours |
| Drop Height Resistance | 70 cm | 70 cm |
| Local Load Capacity | 120 kg | 300 kg |
| Operating Temperature | 10–35°C | 10–35°C |
| Operating Humidity | 10–90% RH | 10–90% RH |
| Storage Temperature | -10–50°C | -10–50°C |
| Storage Humidity | 10–90% RH | 10–90% RH |
Application Scenarios
- Hospital Radiology Departments: General radiography, chest, abdominal, skeletal imaging
- Mobile Radiography: Wireless mobility for emergency and bedside examinations
- Imaging Centers & Clinics: High‑sensitivity, low‑dose digital radiography
- Orthopedic & Trauma Imaging: Durable design for high‑load and emergency use
- Veterinary Radiography: Suitable for large and small animal imaging workflows
