Full Product Description
The FTLENT-HFC1 Portable Fundus Camera is designed for efficient retinal photography in clinics, screening programs, and mobile ophthalmic applications. Its compact handheld design allows convenient imaging without the need for a large tabletop system. The camera provides a 45° field of view, 1920×1080 image resolution, and eight internal fixation targets to assist with retinal positioning. Diopter compensation from -20D to +20D supports a wide range of patients, while IR and white LED imaging modes provide flexible examination options. Connectivity features include PC software connection, DICOM compatibility, NFC support, and optional ID card reader functionality in supported regions. The rechargeable 3400mAh lithium battery provides up to approximately 6 hours of working time.
Key Features
• Portable handheld fundus camera
• 45° field of view
• 1920×1080 image resolution
• Minimum pupil size: 2.5mm
• 8 internal fixation targets
• Diopter compensation: -20D to +20D
• IR and white LED imaging modes
• 3.97-inch TFT-LCD screen
• PC software connectivity
• DICOM compatible
• NFC reader support
• ID card reader support in selected regions
• Rechargeable lithium battery
• Up to approximately 6 hours working time
• Suitable for retinal screening and ophthalmic examination
Specifications
Model: FTLENT-HFC1
Product Type: Portable Fundus Camera
Field of View: 45°
Minimum Pupil Size: 2.5mm
Image Resolution: 1920 × 1080
Fixation Targets: 8 Internal Fixation Targets
Diopter Compensation: -20D to +20D
Image Modalities: IR / White LED
Display: 3.97-Inch TFT-LCD
PC Connection: Software Connection to PC
DICOM Compatibility: Yes
NFC Reader: Supported
ID Card Reader: Supported in Specific Countries
Battery Type: Lithium Battery
Battery Voltage: 3.7V
Battery Capacity: 3400mAh
Working Time: Up to Approximately 6 Hours
Application: Fundus Photography / Retinal Imaging / Ophthalmic Screening
Recommended Use: Eye Clinic / Mobile Screening / Ophthalmology Department
