Key attributes
Industry-specific attributes
Warranty
1 Year
After-sale Service
Online technical support
Other attributes
Instrument classification
Class II
Place of Origin
Guangdong, China
Brand Name
Fatali
Model Number
FTL-F800
Power Source
Electric
Shape
Rectangular
Application
medical diagnosis, radiography department, x-ray photography
Shelf Life
1years
Quality Certification
ce
Product name
Portable X-ray machine
Color
Picture Shown
Working frequency
80~200kHz
Frequency
50Hz/60Hz
Usage
Doctor’s Diagnosis
Power Source
Electric
Feature
Durable Convenient Easy Operation
Advantage
Professional Manufacturer
Port
Guangzhou,Shenzhen
Packing
Wooden Box
Product descriptions from the supplier
Products Description
| Project | 800W Portable X Ray Specification | |
| Charger | Input | mono-phase，AC power 220V±10% |
| Frequency | 50Hz/60Hz±1Hz | |
| Output | 25.2 VDC ，1.5A | |
| Battery | 22.2V（polymer lithium ion），5000mAh | |
| kV | 40 -85 kV (step:1 kV ) | |
| mA | 1- 16mA (step:1 mA ) | |
| X-ray release time range | 0.03-0.20secs（step: 10millisecond）
0.010-4.00secs（step: 50millisecond） |
|
| Screen | 8” inches (resolution: 1280×800) IPS | |
| X-ray tube | Model | |
| Inherent filter | 0.5mm AL | |
| Focus point | 0.8X0.8mm | |
| CPU | 8G/16G，256GeMMC, WIFI6 | |
| Dimension | 280mm x 155mm x 65mm （length×width×height） | |
| Weight | 2.8kg±5% | |
