FTLNJ-DQ-4 Resectoscopy Set – Urological Endoscopic Surgical Instrument Set
The FTLNJ-DQ-4 Resectoscopy Set is a specialized medical instrument system designed for compatible urological endoscopic resection procedures. Featuring a 30-degree rigid endoscope, passive working element, inner and outer sheaths, multiple electrode configurations, and electrosurgical accessories, the set provides a coordinated solution for appropriately equipped urological operating rooms.
The FTLNJ-DQ-4 includes a 30° endoscope measuring 4 mm in diameter and 302 mm in length, along with a 24.5Fr inner sheath with obturator and a 26.5Fr outer sheath.
Its range of loop, roller, spike, and spud electrodes provides different working-tip configurations for manufacturer-approved resectoscopic electrosurgical applications.
Key Features & Benefits
1. 30-Degree Rigid Endoscope
Features a 30° rigid endoscope with Ø4 × 302 mm dimensions, designed to support visualization during compatible urological endoscopic procedures.
2. Passive Working Element
Includes a passive working element intended to support controlled manipulation of compatible resectoscopic electrodes.
3. Inner Sheath with Obturator
The 24.5Fr inner sheath with obturator is designed for integration with the appropriate resectoscopic access assembly.
4. 26.5Fr Outer Sheath
Includes a 26.5Fr outer sheath for use with compatible endoscope and working-element configurations.
5. 30-Degree Loop Electrode
Features a catalog-listed 30° loop electrode for suitable electrosurgical resection applications.
6. Roller Electrode
Includes a roller electrode configuration for manufacturer-approved electrosurgical tissue treatment.
7. Spike and Spud Electrodes
Provides additional spike and 30° spud electrode options for compatible surgical instrument configurations.
8. Ellik Evacuator
The supplied Ellik evacuator is intended to support appropriate fluid and material evacuation during compatible endoscopic procedures.
9. Light Guide Cable
Includes a 4.5 mm diameter, 2000 mm long light guide cable for connection to compatible medical illumination equipment.
10. Electrosurgical Accessories
The catalog lists a high-frequency cord and a multifunctional HF electrosurgical generator as components of the product configuration.
11. Connection Adaptors
Includes a standard adaptor, Luer-lock adaptor, and evacuator adaptor to support assembly with suitable accessories.
Applications
The FTLNJ-DQ-4 Resectoscopy Set may be suitable for:
- Compatible urological resectoscopy procedures
- Hospital urology departments
- Endoscopic urological surgery
- Minimally invasive urological treatment facilities
- Medical centers using compatible electrosurgical resectoscopy equipment
Specific clinical indications, electrode compatibility, approved electrosurgical generators, and procedural requirements must be confirmed through the manufacturer’s instructions for use.
Technical Specifications
| Specification | Details |
|---|---|
| Product Model | FTLNJ-DQ-4 |
| Product Name | Resectoscopy Set |
| Product Category | Urological Endoscopic Instruments |
| Equipment Type | Endoscopic Resectoscopy Instrument Set |
| Endoscope Viewing Angle | 30° |
| Endoscope Diameter | 4 mm |
| Endoscope Length | 302 mm |
| Working Element | Passive |
| Inner Sheath with Obturator | 24.5Fr |
| Outer Sheath | 26.5Fr |
| Loop Electrode | 30° |
| Roller Electrode | Included |
| Spike Electrode | Included |
| Spud Electrode | 30° |
| Standard Adaptor | Included |
| Luer-Lock Adaptor | Included |
| Light Guide Cable | Ø4.5 × 2000 mm |
| Evacuator | Ellik |
| Evacuator Adaptor | Included |
| High-Frequency Cord | Listed |
| HF Electrosurgical Generator | Multi-Functional (Catalog Listed) |
| Primary Function | Compatible Endoscopic Urological Resection |
Why Choose the FTLNJ-DQ-4 Resectoscopy Set?
The FTLNJ-DQ-4 combines a 30-degree rigid endoscope, passive working element, multiple sheath components, and specialized electrodes in a coordinated surgical instrument configuration.
Its selection of resectoscopic electrodes, evacuation accessories, and connecting components offers flexibility for appropriately configured urological endoscopic procedures.
For hospitals, urology departments, and medical equipment suppliers seeking a comprehensive resectoscopy instrument set, the FTLNJ-DQ-4 provides a broad selection of catalog-listed instruments and accessories for equipment evaluation.
