FTLNJ-DL4 4K UHD – Ultra HD Medical Endoscopy Camera System
The FTLNJ-DL4 4K UHD Camera System is a high-resolution medical imaging solution designed for compatible endoscopic and minimally invasive surgical visualization systems. Featuring a 1/3-inch progressive-scan color CMOS image sensor and 3840 × 2160 Ultra HD resolution, the system is designed to deliver detailed images and vivid color reproduction.
With approximately four times the pixel count of conventional 1920 × 1080 Full HD imaging, the FTLNJ-DL4 provides enhanced image detail to support visual examination during compatible endoscopic procedures.
The system features a user-oriented control interface and multiple video output options, including HDMI and SDI connections, supporting integration with suitable medical displays and video equipment.
Key Features & Benefits
1. 4K Ultra High-Definition Imaging
Delivers 3840 × 2160 pixel imaging, providing high-resolution visualization for compatible medical endoscopy applications.
2. Progressive-Scan CMOS Sensor
Equipped with a 1/3-inch progressive-scan color CMOS imaging sensor designed to support detailed image capture and consistent color reproduction.
3. Four Times the Pixels of Full HD
4K UHD resolution provides approximately four times as many pixels as conventional 1920 × 1080 Full HD, allowing finer visual detail when used with compatible equipment.
4. Detailed Image Reproduction
The product catalog specifies a horizontal resolution of 1600 TV lines, intended to support detailed imaging and visual clarity.
5. User-Friendly Control Interface
Features a control interface designed to simplify adjustments and provide convenient access to supported camera functions.
6. HDMI Video Connectivity
HDMI output options support integration with compatible digital medical monitors and visualization equipment.
7. SDI Video Connectivity
SDI interface options support connectivity with suitable professional and medical video equipment.
8. Compact Medical Imaging Processor
The rectangular processor design supports organized installation in compatible endoscopy towers and medical imaging workstations.
Applications
The FTLNJ-DL4 4K UHD Camera System may be suitable for:
- Rigid endoscopy systems
- Laparoscopic imaging
- Minimally invasive surgical visualization
- Hospital operating rooms
- Medical endoscopy departments
- Compatible surgical camera and display systems
Specific clinical indications and device compatibility must be confirmed through the manufacturer’s instructions.
Technical Specifications
| Specification | Details |
|---|---|
| Product Model | FTLNJ-DL4 |
| Product Name | 4K UHD |
| Product Category | Medical Endoscopy Imaging |
| Equipment Type | Ultra HD Endoscopy Camera System |
| Image Sensor | 1/3-Inch Progressive Color CMOS |
| Resolution | 3840 × 2160 Pixels |
| Horizontal Resolution | 1600 TV Lines (Catalog Claim) |
| Image Quality | 4K Ultra HD |
| Video Output Interfaces | HDMI / SDI (Catalog Listed) |
| Control Interface | Front-Panel User Controls |
| Primary Function | Endoscopic Video Imaging |
Why Choose the FTLNJ-DL4 4K UHD Camera System?
The FTLNJ-DL4 combines 4K Ultra HD resolution, progressive CMOS imaging technology, and multiple video interface options to support detailed visualization in compatible medical endoscopy systems.
Its 3840 × 2160 resolution provides four times the pixel count of standard 1080p Full HD, while its user-friendly controls and digital video connections support practical equipment integration.
For hospitals, surgical departments, and endoscopy facilities evaluating high-resolution visualization equipment, the FTLNJ-DL4 offers a medical camera system with clearly specified imaging capabilities and flexible connectivity options.
