| X-ray bed | |
| Bed body size | Length2090 * Width800 * Height688mm |
| The Movement distance of bed surface broad toward the left or right direction | ±430mm |
| The Movement distance of bed surface broad toward the front or back direction | ±107mm |
| The Left and right movement distance of the tray under the bed | 460mm |
| Pillar above the bed | |
| X-ray tube pillar size | Height2130*230*150mm |
| The Movement distance toward the left or right direction | 1380mm |
| X-ray tube rack arm | |
| Length | |
| The highest distance from the ground | 1700mm |
| The lowest distance from the ground | 460mm |
| The movement distance from up and down | 990mm |
| Chest X-ray holder | |
| Holder size | Height 2060* Width 260* thickness 220mm |
| Chest X-ray box | width 535mm*540mm |
| The highest distance from centre position to the ground | 1610mm |
| The lowest distance from centre position to the ground | 575mm |
| The distance of up and down movement | 1035mm |
