The Professional Digital 18-Lead ECG Machine (iMAC 1800) is an advanced electrocardiograph designed for hospitals, cardiac centres, clinics, and diagnostic laboratories. Equipped with intelligent ECG analysis technology, high-resolution waveform acquisition, and a 15-inch HD display, it delivers fast, accurate, and reliable cardiac examinations. The system supports both 12-lead and 18-lead synchronous ECG acquisition, making it suitable for comprehensive cardiovascular diagnosis.
Key Features
- 12 & 18-Lead Simultaneous ECG Acquisition
- 15-inch High-Resolution LCD Display
- Professional Intelligent ECG Analysis
- 32,000 Hz High-Speed Digital Sampling
- 24-bit High-Precision A/D Converter
- Ultra-Wide Frequency Response (0.01–350 Hz)
- Integrated Multi-Axis Thermal Printer
- QWERTY Keyboard with Shortcut Keys
- Trackball Mouse for Easy Navigation
- Supports Adult, Pediatric & Elderly Patients
- USB, VGA, RS232 & SD Card Connectivity
- External Display Support via VGA
- High-Quality ECG Waveform Printing
- Portable Design with Comfortable Carry Handle
- Advanced Digital Filtering for Noise Reduction
Key Attributes
- Professional Hospital-Grade ECG System
- High Diagnostic Accuracy
- Intelligent ECG Interpretation
- User-Friendly Interface
- Fast ECG Recording & Printing
- Durable & Reliable Performance
- Suitable for Continuous Clinical Use
- Multi-Interface Data Transfer
- Digital Signal Processing Technology
- High-Speed Thermal Printing
- Easy Data Storage & Export
- Low Noise Signal Acquisition
- Compact & Modern Design
- Ideal for Hospitals, Cardiology Departments & Diagnostic Centres
Technical Specifications
| Specification | Details |
|---|---|
| Product Model | iMAC 1800 |
| ECG Channels | 12 & 18 Lead |
| Display | 15-inch High-Resolution LCD |
| Sampling Rate | Up to 32,000 Hz |
| A/D Converter | 24-bit |
| Frequency Response | 0.01–350 Hz |
| Sensitivity | 2.5, 5, 10, 20, 40 mm/mV, Auto |
| Paper Speed | 5, 6.25, 10, 12.5, 25, 50 mm/s |
| Printer | Integrated Multi-Axis Thermal Printer |
| Keyboard | Full QWERTY Keyboard |
| Navigation | Trackball Mouse |
| Connectivity | USB, VGA, RS232, SD Card |
| External Display | Supported (VGA) |
| Patient Types | Adult, Pediatric & Geriatric |
| Signal Processing | Intelligent Adaptive Digital Filtering |
| Application | Hospital, Clinic, Cardiac Centre, Diagnostic Laboratory |
