Full Product Description
The FTLDEN-E100 Dental Implant Motor is designed to provide precise speed, torque, and irrigation control during dental implant procedures. The system supports motor speeds from 500 to 40,000 RPM with a 1:1 ratio and torque adjustment from 10 to 60 N·cm when used with a 20:1 contra-angle. Its coolant system provides adjustable flow from 0 to 100ml/min to help support efficient irrigation during surgery. The unit can store up to 10 treatment programs, while the multifunction foot control allows the operator to adjust coolant flow, change programs, control forward/reverse rotation, and manage speed without interrupting the procedure.
Key Features
• Professional dental implant motor system
• 210W output power
• Motor speed range: 500–40,000 RPM
• Adjustable torque: 10–60 N·cm
• Supports 20:1 implant contra-angle
• Adjustable coolant flow: 0–100ml/min
• Stores up to 10 treatment programs
• Multifunction foot control
• Forward and reverse rotation control
• Adjustable speed control
• Coolant flow control from foot pedal
• Suitable for implant surgery and surgical drilling
• Designed for professional dental clinics
Specifications
Model: FTLDEN-E100
Product Type: Dental Implant Motor
Input Power Supply: AC100–110V or AC220–240V
Frequency: 50/60Hz
Output Power: 210W
Motor Speed Range: 500–40,000 RPM
Speed Ratio: 1:1
Torque Range: 10–60 N·cm
Torque Ratio: 20:1
Coolant Flow: 0–100ml/min
Stored Programs: 10 Programs
Rotation Control: Forward / Reverse
Foot Control Functions: Coolant Flow / Program / Forward / Reverse / Speed
Application: Dental Implant Surgery / Surgical Drilling
Recommended Use: Dental Clinic / Implant Treatment Room
Power Source: Electric
