Product Description
The A-3 Three-Crank Mechanical Hospital Bed is designed to provide reliable patient support and flexible positioning in hospitals, clinics, nursing facilities, and other healthcare environments. Its three-crank mechanical adjustment system allows caregivers to manually adjust the backrest, legrest, and overall bed height according to patient and care requirements.
The bed features a cold-rolled steel bed board formed through a punching and shaping process, together with an epoxy-coated steel frame designed for corrosion resistance. The detachable ABS head and foot boards are lockable, while the aluminum alloy foldable side rails provide convenient access and patient protection.
For mobility and secure positioning, the A-3 is equipped with four 125mm castors with a central braking system. The bed supports a maximum load of 235kg, making it suitable for routine hospital patient care.
Key Features
- Three-crank mechanical adjustment system
- Adjustable backrest from 0° to 75°
- Adjustable legrest from 0° to 45°
- Manual bed height adjustment from 500 to 720mm
- Detachable and lockable ABS head and foot boards
- Cold-rolled steel bed board
- Epoxy-coated steel frame with corrosion-resistant finish
- Aluminum alloy foldable side rails
- Four 125mm castors
- Central braking system
- Maximum load capacity of 235kg
- Optional dinner table
- Optional height-adjustable IV stand with double hooks
- Optional mattress
Technical Specifications
| Specification | Details |
|---|---|
| Model | A-3 |
| Product Type | Three-Crank Mechanical Hospital Bed |
| Operation | Manual / Mechanical |
| Backrest Adjustment | 0°–75° |
| Legrest Adjustment | 0°–45° |
| Height Adjustment | 500–720mm |
| Bed Board Material | Cold-Rolled Steel |
| Frame Material | Epoxy-Coated Steel |
| Head & Foot Boards | Detachable ABS, Lockable |
| Side Rails | Aluminum Alloy, Foldable |
| Castors | 4 × 125mm |
| Braking System | Central Braking |
| Maximum Load Capacity | 235kg |
| Dinner Table | Optional |
| IV Stand | Optional, Height Adjustable, Double Hooks |
| Mattress | Optional |
Ideal For
The A-3 Three-Crank Mechanical Hospital Bed is suitable for:
- Hospitals
- General wards
- Clinics
- Nursing facilities
- Patient recovery areas
- Long-term care environments
- General inpatient care
